Capacity

MACHINE CAPABILITY LIST





S/N Device Machine stroke (mm) Accuracy
X Y Z Max Weight
1 CNC Machining Center 1100 600 600     0.01 mm
2 CNC Machining Center 1100 600 600     0.01 mm
3 CNC Machining Center 1100 600 600     0.01 mm
4 CNC Machining Center 1100 600 600     0.01 mm
5 CNC Machining Center 850 500 500     0.01 mm
6 CNC Machining Center 850 500 500     0.01 mm
7 EDM 600 400 400     0.01 mm
8 EDM 600 400 400     0.01 mm
9 EDM 600 400 400     0.01 mm
10 Manual Mill 800 400 500     0.01 mm
11 CNC Lathe       400 1000 0.01 mm
12 CNC Lathe       400 850 0.01 mm
13 CNC Lathe       300 750 0.01 mm
14 CNC Lathe       300 500 0.01 mm
15 CNC Lathe       200 500 0.01 mm
16 Manual Grinder 600 400 500     0.01 mm

TEST EQUIPMENT





S/N Device Brand Measuring range Accuracy
1 Altimeter TRIMOS 0-700 mm 0.01 mm
2 Block gauge Mitutoyo 0-100 mm 0.01 mm
3 Outside diameter micrometer Mitutoyo 0-25 mm 0.01 mm
4 Outside diameter micrometer Mitutoyo 25-50 mm 0.01 mm
5 Outside diameter micrometer Mitutoyo 50-75 mm 0.01 mm
6 Inside micrometer Mitutoyo 5-30 mm 0.01 mm
7 Inside micrometer Mitutoyo 25-50 mm 0.01 mm
8 Plug Gauging Chengdu Measuring Tool 0-100 mm 0.01 mm
9 Block Gauging Chengdu Measuring Tool 1-100 mm 0.01 mm
10 Thread Ring and Plug Gauges Chengdu Measuring Tool M2-M20 -
11 Caliper Mitutoyo 0-150 mm 0.02 mm
12 Three coordinates measuring machine Hexagon 500*500*400 mm 0.001 mm
